Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298

Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298
Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298Ridetech 1978-1988 GM G-Body HQ Series Air Suspension System 11320298
$8,759.99 kt
NEWARRIVING SOONEstimated Ship Date 11/27/2024 (If Ordered Today)1 Available from RIDETECH as of 11/07/2024
Model: 3429409
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
SHIPPING
INCLUDED
STORE PICKUP
[More Info]

Air Suspension System with ShockWaves® for 1978-1988 GM "G" Body cars including Monte Carlo, Regal, Cutlass, Grand Prix, Lemans, El Camino and variants. Includes front & rear HQ Series ShockWaves® with integral rebound adjustable shock absorbers, front & rear StrongArm control arms and front & rear MuscleBars. This air ride system takes the guesswork out of choosing the correct air springs and suspension parts for proper handling and ride quality. The heart of the system is Ridetech's exclusive monotube shock absorber technology with 24-position rebound adjustment to help you fine tune for your driving preferences and vehicle demands. Advanced technology hides within the shocks. The monotube design features large 1.834" pistons, heavy duty 5/8" shafts, and impact-forged bodies. Since HQ Series ShockWaves® are built to perform and made to last, they are backed by RideTech's exclusive 1,000,001 mile warranty. Based on more than 20 years of R&D, the air springs are correctly sized for Monte Carlo, Grand National, T-Type, 442, Hurst/Olds, El Camino and all G-body variants. All components are available separately as well.

Features:

  • TheUpper StrongArmsfeature tall ball joints to provide increased camber gain and the ball joint location has been moved back to allow for additional caster setting to improve high speed stability and steering feel. Offset slugs are also available for additional caster. Injection molded Delrin bushings with 13% Teflon are used to reduce deflection and stiction.
  • TheLower StrongArmsfeature a double sheer lower mount for increased strength. We have also dropped the lower shock mount to increase suspension travel and moved the lower ball joint forward to increase caster settings while keeping the wheel centered in the wheel opening. Injection molded Delrin bushings with 13% Teflon are used to reduce deflection and stiction.

  • New Heim Style outer tie rods, studs and adusters are included to correct the bumpsteer.

  • HQ Series Shockwavesutilize an impact forged aluminum body and Monotube design to deliver excellent ride quality and handling. They allow fine tuning of the ride quality and handling the rebound knob is located at the top of the shock for under hood access. They come standard with a 1,000,0001 Mile Warranty. Brackets are included witht the rear coilovers for easy attachment to the frame and to the 10/12 bolt rearend.
  • ThisFront MucleBarhelps reduce body roll and creates room for wider front tires. It includes the PosiLink endlinks that provide immediate engagement between the chassis and control arms. ARear MuscleBaris also included.

  • The Rear StrongArms provide added strength to help get the power to the pavement and utilize R-Joint Technology to combine the best qualities of low friction movement, lateral stability, full range articulation, and quiet operation into one special bearing that is as home on the street as it is on the racetrack.

To complete this Air Suspension system please choose from one of our Compressor Systems .

WARNING: Cancer and Reproductive Harm

About Ridetech

Ridetech manufactures exciting suspension systems that improve the handling and ride quality of your muscle car, truck, Corvette or hot rod. From restorations and show cars, to high-speed autocross and track day cars, Ridetech offers a wide range of premium products including air suspension systems (air ride), coil-overs, shock absorbers, coil and leaf springs, tubular control arms, roll bars, sway bars and much more.

Downloads:

Download Name File Size
11320298_WEB_composite_RJOINT1.pdf3.59MB

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Years
Chevrolet El Camino 1978 - 1987
Chevrolet Malibu 1978 - 1983
Pontiac Grand Prix 1978 - 1987
