MSD Pro Mag Generator Band Clamp 81602

Name: MSD Pro Mag Generator Band Clamp 81602
Brand: MSD
SKU: 4017491
Price: 6051.99 CAD
Availability: InStock

$6,051.99 ea

NEWARRIVING SOONEstimated Ship Date 01/07/2025 (If Ordered Today)4 Available from HOLLEY PERFORMANCE PRODUCTS as of 12/22/2024

Model: 4017491

0 reviewsWrite a Review Add to Wish List

CALL US
877.454.7792

Description Downloads Video Specifications Reviews (0) Product Q&A Related Products

The increased out put of the 20 Amp pro-mag was born of racers being racers; always asking for more power. This stemmed from drag racers that were using a 12 Amp system, but just didn't require a 44 Amp system. The engineers at MSD found that with a few changes to the internals of the generator it would deliver the increased current through the same electronic points box, PN 8106. The 20 Amp magneto is a favorite in alcohol slurping engines such sportsman drafters and quick-8 racers. There are three different generators available; a band clamp design in both CW and CCW rotation, plus a model built on a Chevy distributor base. All three require the PN 8106 electronic points box. The band clamp versions are equipped with a large Ford style cap while the Chevy version uses a 4 In. cap and both are topped with heavy duty retainers.

Features:

Pro Mag Generator Band Clamp

Holley Performance Emission Code 4: This part is legal for sale or use on Racing Use Only Vehicles. The following vehicles are considered Racing Use Only Vehicles: Racing Use Only Vehicles are vehicles that are used exclusively for competition that are not registered and that may never be used on the street. WARNING: It is against the law to install this part on an Emissions Controlled Vehicle

About MSD Ignition

Racers never stop experimenting as they search for every way to wring out more power or handling performance to to gain an edge over the competition. The team at MSD is no different as we strive to deliver the products you need to meet your performance goals. We continue to innovate and invent components and technology that deliver performance and reliability with products that are easy to use and install.

Over the course of 40-plus years, MSD Performance has been driving the development of innovative components that helped shape the way our cars race and perform. From super speedways to road courses, land speed racing to top fuel dragsters, and of course your traditional hot rod, MSD has provided the components to fire nearly anything in motorsports.

MSD was the first company to develop and offer the multiple sparking, capacitive discharge ignition for engines. The line of MSD 6-Series Ignitions are the most popular aftermarket ignitions in the world due to our race-proven performance on the track and our reliability on the street!

Early on, MSD focused squarely on ignition systems with revolutionary products like the multiple sparking CD ignition, timing and rev controls, billet aluminum distributors and the Pro-Mag, an incredible breakthrough in power and endurance.

Today MSD is developing electronics for your entire powertrain. The Atomic EFI systems for the LS engine platform and throttle body are now complemented with a transmission controller. Our DynaForce Starters and Alternators ensure that your engine cranks over to fire up and the Alternators keep it charged. MSD is poised to deliver components that work and communicate together to provide performance and value.

Downloads:

Download Name	File Size
81602.pdf	630.44KB

Videos:

Specifications:

Color	Red
Emission Code	4
Finish	As Cast
Part Type	Generator Bracket
Primary Current	20 Amp
RPM	14000
RPM Rating	through 14,000 rpm
Secondary Current	300 Milliamp
Secondary Voltage	40000
Spark duration	26 Degree Crankshaft Rotation, 26° crankshaft rotation
Spark Energy	240 mJ per spark
Style	Straight
WARNING CA Proposition 65	WARNING: Cancer and Reproductive Harm
